Features:

1. 16 Channels

2. Powerful Output: 5W/7W

3. CTCSS/DCS Encode & Decode

4. Dual PTT Buttons & Dual Channels Standby

5. Priority Scan Mode

6. Wide/Narrow Bandwidth 25KHz/12.5KHz(selective)

7. VOX Programmable(10 levels selective)

8. Powerful Audio Output 1W

9. Auto Battery Save

10. Emergency Alarm

11. TOT(Time Out Timer)

Specifications：

General
Frequency Range	136-174MHz/245MHz/350-390MHz/400-470MHz/470-520MHz
Channel Capacity	16 Channels
Operation Voltage	7.4V DC ± 10%
Channel Spacing	25KHz(Wide) / 12.5KHz(Narrow)
Antenna Impedance	50Ω
Battery Capacity	1500mAh/2000mAh(Li-Ion Battery)
Battery Life(5-5-90 Duty Cycle)	Around 15/20hours
Operating Temperature	-30°c ~ +60°c
Frequency Stability	± 2.5ppm
Dimension(W*H*D)(Projections excluded)	53*28*116mm
Weight(Antenna & Battery Included)	216g

Transmitter(ETSI EN 300 086 Testing Standard)
Bandwidth	Wide Band 25KHz	Narrow Band 12.5KHz
RF Power Output(High/Low)	7W/5W
Modulation	16KΦF3E	11KΦF3E
Spurious Emission	≥36dB	≥36dB
Adjacent Channel Power	≥70dB	≥60dB
Hum & Noise	≥40dB	≥36dB
Audio Response	+1 ~ -3dB(0.3~3KHz)	+1 ~ -3dB(0.3~2.25KHz)
Modulation Limiting	±5.0KHz	±2.5KHz
Modulation Distortion	Less than 5%
Frequency Stability	+/- 5ppm

Receiver(ETSI EN 300 086 Testing Standard)
Bandwidth	Wide Band 25KHz	Narrow Band 12.5KHz
Sensitivity (12dB SINAD)	≤0.25μV	≤0.35μV
Adjacent Channel Selectivity	≥70dB	≥60dB
Intermodulation	≥65dB	≥60dB
Spurous Response Rejection	≥70dB	≥70dB
Audio Response	+1 ~ -3dB(0.3~3KHz)	+1 ~ -3dB(0.3~2.25KHz)
Hum & Noise	≥45dB	≥36dB
Audio Distortion	≤ 5%
Audio Output	1W with less than 10%
