Features:

1. Output Power: 25W(VHF) / 20W(UHF)
2. 200 programmable memorized channels
3. CTCSS/DCS/2Tone/5-Tone decode and encode
4. Alphanumeric Programmable
5. Remote Stun/Remote Kill
6. With FM Radio Function
7. Emergency Alarm
8. DTMF/PTT ID.
9. Multifunctional Microphone with DTMF
10. Three Color LED Display Selective

General
Frequency Range	VHF 136-174MHz&400-480MHz VHF 136-174MHz&480-520MHz VHF 245-246MHz&400-480MHz
Number of Channel	200CH
Channel Spacing	25KHz/12.5KHz
Channel Step	5KHz, 6.25 KHz, 10 KHz ,12.5 KHz, 15 KHz, 25 KHz
Working Voltage	13.8V DC±15%
Squelch Way	CTCSS/DCS/5Tone/2Tone/DTMF
Frequency Stability	±2.5ppm
Operation Temperature	-20~+60℃
Dimension(W * H * D)	98x35x118mm
Weight	408g

Transmitter(ETSI EN 300 086 Testing Standard)
Bandwidth	Wide Band 25KHz	Narrow Band 12.5KHz
Power Output	25W/20W (VHF/UHF)
Modulation	16KΦF3E	11KΦF3E
Adjacent Channel Power	≥70dB	≥60dB
Hum & Noise	≥40dB	≥36dB
Harmonic	≥60dB	≥60dB
Audio Response	+1 ~ -3dB(0.3~3KHz)	+1 ~ -3dB(0.3~2.55KHz)
Audio Distortion	Less than 5%

Receiver(ETSI EN 300 086 Testing Standard)
Bandwidth	Wide Band 25KHz	Narrow Band 12.5KHz
Sensitivity (12dB SINAD)	≤0.25μV	≤0.35μV
Adjacent Channel Selectivity	≥70dB	≥60dB
Intermodulation	≥65dB	≥60dB
Spurous Response Rejection	≥70dB	≥70dB
Audio Response	+1 ~ -3dB(0.3~3KHz)	+1 ~ -3dB(0.3~2.55KHz)
Hum & Noise	≥45dB	≥40dB
Audio Distortion	≤ 5%
Audio Output	≥2W@10%
